سنسور القایی اشنایدر الکتریک XS دو سیمه با سری قابل چرخش
Inductive sensor XS7 40x40x117 – PBT – Sn15 mm – 12..48VDC – terminals
| range of product |
OsiSense XS
|
|
|---|---|---|
| series name |
General purpose
|
|
| sensor type |
Inductive proximity sensor
|
|
| device application |
–
|
|
| sensor name |
XS7
|
|
| sensor design |
Form 40 x 40 x 117
|
|
| size |
117 mm
|
|
| body type |
Fixed
|
|
| detector flush mounting acceptance |
Flush mountable
|
|
| material |
Plastic
|
|
| enclosure material |
PBT
|
|
| type of output signal |
Discrete
|
|
| wiring technique |
2-wire
|
|
| [Sn] nominal sensing distance |
15 mm
|
|
| discrete output function |
1 NO or 1 NC programmable
|
|
| output circuit type |
DC
|
|
| electrical connection |
Screw-clamp terminals, 4 x 1.5 mm²
|
|
| [Us] rated supply voltage |
12…48 V DC with reverse polarity protection
|
|
| switching capacity in mA |
1.5…100 mA with overload and short-circuit protection
|
|
| IP degree of protection |
IP67 conforming to IEC 60529
IP65 conforming to IEC 60529 IP69K conforming to DIN 40050 |
detection face |
5 positions turret head
|
|
|---|---|---|
| front material |
PBT
|
|
| operating zone |
0…12 mm
|
|
| differential travel |
3…15% of Sr
|
|
| repeat accuracy |
<= 3% of Sr
|
|
| cable entry number |
1 tapped entry for Pg 13.5 cable gland
|
|
| status LED |
Output state: 1 LED (yellow)
|
|
| supply voltage limits |
10…58 V DC
|
|
| maximum residual current |
0.6 mA open state
|
|
| switching frequency |
<= 300 Hz
|
|
| maximum voltage drop |
<4.2 V (closed)
|
|
| maximum delay first up |
7.5 ms
|
|
| maximum delay response |
1.2 ms
|
|
| maximum delay recovery |
1.8 ms
|
|
| marking |
CE
|
|
| height |
40 mm
|
|
| length |
40 mm
|
|
| width |
117 mm
|
|
| net weight |
0.244 kg
|
| product certifications |
CCC
CSA UL |
|
|---|---|---|
| ambient air temperature for operation |
-25…70 °C
|
|
| ambient air temperature for storage |
-40…85 °C
|
|
| vibration resistance |
25 gn amplitude = +/- 2 mm (f = 10…55 Hz) conforming to IEC 60068-2-6
|
|
| shock resistance |
50 gn for 11 ms conforming to EN 60068-2-27
|
| Package 1 Weight |
0.244 kg
|
|
|---|---|---|
| Package 1 Height |
1.450 dm
|
|
| Package 1 width |
0.500 dm
|
|
| Package 1 Length |
0.500 dm
|
| Sustainable offer status |
Green Premium product
|
|
|---|---|---|
| EU RoHS Directive |
Pro-active compliance (Product out of EU RoHS legal scope)
EU RoHS Declaration |
|
| Mercury free |
Yes
|
|
| RoHS exemption information |
Yes
|
|
| Environmental Disclosure |
Product Environmental Profile
|
